Concise Introduction to Gated DeltaNets

A concise introduction to understanding Gated DeltaNets (used in Qwen3, Kimi K3, Olmo Hybrid)

Mt. Tumanguya (Whitney), Sierra Nevada, California, U.S

LLM inference workloads have been moving towards longer context lengths, stemming from usage from long-running agents and requiring working in large codebases/contexts. This results in two problems: KV cache size grows as $O(T)$ with the length of the sequence $T$, and each decoded token costs $O(T)$.

Linear attention methods have been gaining prominence recently as it avoids both problems entirely. This post is a short introduction to understanding how a recent linear attention technique, Gated DeltaNets (GDN) from Songlin Yang et al. works.

Linear Attention

Recall that in softmax attention:

\[o_t = \sum_{i \le t} \operatorname{softmax}_i(q_t \cdot k_i)\, v_i\]

With this, we must keep all $k_i, v_i$ around (KV cache). This grows linearly with sequence length.

Removing the softmax

Suppose we remove the softmax:

\[o_t = \sum_{i \le t} (q_t \cdot k_i)\, v_i\]

Then we can rewrite:

\[\begin{aligned} (q_t \cdot k_i)\, v_i &= v_i\, (q_t \cdot k_i) \\ &= v_i\, (k_i \cdot q_t) \\ &= v_i\, (k_i^\top q_t) \\ &= (v_i k_i^\top)\, q_t \end{aligned}\]

where $v_i k_i^\top$ is a $D_v \times D_k$ outer product.

This gives:

\[o_t = \underbrace{\left( \sum_{i \le t} v_i k_i^\top \right)}_{S_t} q_t\]

where $S_t$ is the state, of shape $D_v \times D_k$.

Now our state recurrence becomes

\[S_t = S_{t-1} + v_t k_t^\top,\]

which is a $O(1)$ update, and we also no longer have to carry the KV cache around. This is known as linear attention .

Associative memory

$S$ behaves like an associative memory: if you assume all keys added to the state are orthogonal unit vectors, then for query $q = k_j$:

\[\begin{aligned} S_t q &= \left( \sum_{i \le t} v_i k_i^\top \right) k_j \\ &= v_j \end{aligned}\]

Of course, since you are limited to $D_k$ dimensions, storing more than $D_k$ keys leads to overlap, and there is interference in the contribution from the wrong entries when read.

Problems with linear attention

No forgetting

\[S_t = S_{t-1} + v_t k_t^\top\]

The state keeps accumulating. After $n$ tokens, you end up with a sum of $n$ outer products and end up reading noise.

Fix: add a gate to decay the old state:

\[S_t = \alpha_t S_{t-1} + v_t k_t^\top\]

Note that $\alpha_t$ can depend on the current token.

Suppose we write key $k$ with value $v_{\text{old}}$, and now we want to update it to $v_{\text{new}}$.

The update causes $k$ to become: $v_{\text{old}} + v_{\text{new}}$ (or $\text{decay} \cdot v_{\text{old}} + v_{\text{new}}$), i.e an interpolation between the new and old values.

What if we want to be able to revise the value directly?

Fix: what is known as the delta rule .

First, query what the memory currently stores about $k_t$:

\[v_{\text{old}} = \tilde{S} k_t, \quad \text{where } \tilde{S} = \alpha_t S_{t-1}\]

Then update by the error between $v_t$ and $v_{\text{old}}$:

\[S_t = \tilde{S} + \beta_t (v_t - v_{\text{old}})\, k_t^\top\]

where $\beta_t$ is another gating factor that can be input-dependent.

Why is this update good?

Test-time regression

Define the loss to be “how badly do I recall $v_t$ from $k_t$”:

\[\mathcal{L}(S) = \frac{1}{2} \lVert S k_t - v_t \rVert^2, \qquad \nabla_S \mathcal{L} = (S k_t - v_t)\, k_t^\top\]

Then we can see that the update corresponds to a gradient step with learning rate $\beta_t$:

\[S \leftarrow S - \beta_t (S k_t - v_t)\, k_t^\top\]

So this is like running online gradient descent on this regression objective in the forward pass of the state update, with $\beta_t$ as a per-token learning rate, i.e. “test-time regression”.

Erase-then-write

See that the update can be rewritten as:

\[\begin{aligned} S_t &= \tilde{S} + \beta_t (v_t - \tilde{S} k_t)\, k_t^\top \\ &= \tilde{S} - \beta_t \tilde{S} k_t k_t^\top + \beta_t v_t k_t^\top \\ &= \tilde{S} (I - \beta_t k_t k_t^\top) + \beta_t v_t k_t^\top \end{aligned}\]

Suppose keys are $\ell_2$-normalized, so $\lVert k_t \rVert = 1$.

Claim: $(I - \beta k k^\top)$ is a matrix that scales the $k$ direction by a factor of $1 - \beta$.This is a Householder-type transform.

Proof. For some vector $x$, decompose it into directions parallel to and perpendicular to $k$, where $k$ has unit norm:

\[x = \underbrace{(k^\top x)\, k}_{x_\parallel} + x_\perp\]

Then

\[k k^\top x = (k^\top x)\, k = x_\parallel\]

\[\begin{aligned} (I - \beta k k^\top)\, x &= x - \beta k k^\top x \\ &= x - \beta (k^\top x)\, k \\ &= x - \beta x_\parallel \\ &= (1 - \beta)\, x_\parallel + x_\perp \end{aligned}\]

$\blacksquare$

This means that querying the new state with $k_t$ returns

\[S_t k_t = (1-\beta_t)\,\tilde{S} k_t + \beta_t v_t = (1-\beta_t)\, v_{\text{old}} + \beta_t v_t,\]

So, the update uses $\beta_t \in [0, 1]$, to control how much of the old readout is erased, whilst adding the new value.

Gated DeltaNet

Putting everything together, here’s our update:

Decay old state:

\[\tilde{S} = \alpha_t S_{t-1}\]

Read what memory says about $k_t$:

\[v_{\text{old}} = \tilde{S} k_t\]

Correction term:
